Monte Carlo Z34 5-speed swap HOW-TO


carkhz316

Recommended Posts

  • Replies 66
  • Created
  • Last Reply

Top Posters In This Topic

  • carkhz316

    29

  • l67ss

    6

  • nitehawkjcb

    5

  • rich17

    4

Top Posters In This Topic

Popular Posts

At this point, I really wanted to see what that big 'ol Getrag looks liked bolted to the 3800, and to test fit it of course   I thought it looked pretty sweet.   I also wanted to find out how

Posted Images

  • 2 months later...

Just a little update. I finally got around to playing with HP Tuners a few days ago and turned off/ disabled all the trans codes and now the cruise control works. My wiring procedure for the clutch switch works as planned too. With a touch of the brake pedal or the clutch pedal the cruise disables as expected.

Link to post
Share on other sites

I'm guessing some folks just have general problems with the cruise being inoperable. In the case of the manual trans swaps, it's a matter of either the range position switch being in the right position to enable cruise (drive range) and/ or the trans codes inhibiting cruise. My dumb ol' Haynes manual doesn't give pin numbers/ letters for most of the wiring diagrams (cruise control module included) so I had to do some digging to guess which one of the 2 dark green wires was the VSS and which one was the cruise inhibit. I thought if I bypassed the the inhibit signal that it would force the cruise to engage. It turns out I had pulled the VSS wire instead, because when I plugged it back in (after already turning off the trans codes in the PCM) it started working. Regarding the wiring I did in my swap: that was just for the disable to work with the clutch pedal as well as the brake. While not absolutely necessary, I wanted the redundant, factory like function of it; and for safety and stuff.

Link to post
Share on other sites
  • 2 weeks later...

Yup i like hard copies of info i need in case the electronic source fails or i go very long w/o net service. Printed bumpin96montes l67 swap how to off mymonte.com, 6 monthes later the forum died

You actually printed this thread?
Link to post
Share on other sites
Yup i like hard copies of info i need in case the electronic source fails or i go very long w/o net service. Printed bumpin96montes l67 swap how to off mymonte.com, 6 monthes later the forum died



Ugh. We died a slow painful death. I wish chad would have switched over to here. I think he pops up on MCF every once in awhile, but I would love to know how he's doing with the whipple set up these days.

Link to post
Share on other sites
