White93z34

The Parts Number Thread!!

Recommended Posts

Someone suggested we have a Thread dedicated to parts numbers, And that is an excellent Idea. I'm going to keep this open and you can post whatever you feel is helpful to the community. I will be deleting the replys after I paste them into this Post to keep it uncluttered.



Unless noted these are Manufacturer Part numbers and will be the same regardless of who you buy from





Brakes:



Power Master III Parts:

88927271 / 18M874 - accumulator

88927270 - pressure switch

SIA Electronics - Call for pricing and parts (800) 737-0915



Goodridge SS brake lines:

'88-'90 W - GS12264

'94-'97 W - GS12237



Suspension:

GMPP rear trailing arms - 12498649

Police Package Impala trailing arms- 15856683 - QTY2

Hub to knuckle bolts(1 and 1.5 gen front only) - 10104548



KYB GR2/Excel G Front Sturts - 366004

KYB GR2/Excel G Rear Struts - 236003



Energy Suspension greasable poly sway bar bushings (when using 34mm front sway bar) - 9.5160G and 9.5167G



Rear sway bar bracket - 10259660





Engine:

Oil Filters:

2.8/3.1/3x00/3800 - PF47

3.4 - PF52

Note: You can use the PF52 on just about anything that calls for a PF47.



Knock Sensor (genII 60*)- 10456208

Crank Position Sensor (CPS) (GenII 60*) - 10456555



oil/distributor drive O-Ring - 10477565



Oil plug bolt thread size - M12-1.75

Oil drain plug - 10017615

aftermarket Magnetic plug - Motormite "Oil-tite!" 65372

Dorman Quick Disconnect 800-401 - Cooling System Connector that screws into the LIM of 3.1mpfi, earlier 3100sfi, earlier 3400sfi, and 3.4DOHC cars.



3.4 DOHC Timing Belt Parts:

24502982 - Belt

24503561 - Tensioner Pulley

10162013 - Tensioner Pulley Bolt

24503859 - Idler Pulley, 2 needed

24503860 - Tensioner Actuator

24503861 - Tensioner Actuator mounting plate.



89017825 - Improved aluminum Series II 3800 intake gaskets



2.8/3.1 Throttle Body gasket - Fel-pro 60728



91-97 LQ1 Solid rubber engine mount - DEA/Pioneer P/N - A2555 (Available from Autozone)

88-93 2.8/3.1 Solid rubber engine mount - DEA/Pioneer P/N - A2660 (Available from Autozone)

94-96 3100 Solid rubber engine mount - DEA/Pioneer P/N - A2796 (Available from Autozone)

97-04 W-Body Solid rubber engine mount(EXCEPT 3.5L Intrigue) - DEA/Pioneer P/N - A2796 (Available from Autozone)



2.8/3.1 Oil Pressure Sending Unit w/ Gauge (Seems to be for any 60 degree W from 89-90): GM part number 10201491.





Transmission:



4T60-E VSS - 10456034



4T60-E Parking Brake Actuator - 24213560



Getrag 284

Spec Stage II Clutch - SC272

Output Shaft Seals Timken P/N - 2003N

284 select cable - 10192248

284 Slave Cylinder - 12550806



282/284 Clutch pedal bushing - 14091384



Interior:



GM W-body Door Key "C": 12390306

GM W-body Ingition Key "D": 26002688

GM W-body Ignition key "E": 26024974





Body/Misc:



97-00 - Regal GS and Grand Prix GTP fuel pump resistor - 88951182



1st gen Hood release cable - 10167401



94-96 GP Fender flare Clips - 10229345



Power steering rack pressure switch - 10238816



Subframe Bushings

14088025 - QTY2

14088026 - QTY2

14088027 - QTY2

14088028 - QTY2



Subframe Bolts

10220561 - QTY4



Subframe Retainers

10139080 - QTY2

10203413 - QTY2



Fuel Tank Lines for 88-91 W bodys

10062887 PIPE ASM FUEL RTN

10062888 PIPE ASM FUEL FEED



AC Accumulator:

4 Season's PN# 33206 - VERY useful for 284 cars and Turbo Grand Prix

Edited by White93z34

Share this post


Link to post
Share on other sites

Maybe add a link to my GP Parts catlalog scans since there are TONS of GP part #'s there along with a lot of generic w-body part #'s from 88-96?....and since nobody goes to the 2nd page of the FAQ. :lol:



http://s44.photobucket.com/albums/f14/platjblser/



^Click the "GP parts catalog scans" album at the left of the screen after following that link.

Edited by mfewtrail

Share this post


Link to post
Share on other sites

Injector O-rings:



multitech 1

BWD 274573 (formerly GP Sorensen 800-9220) brown silicone

*kit contains 12 o-rings, not 8 as sometimes listed

*half the kit will do the top half of multitech 2 injectors.

(carried by Advance autoparts)

*** BWD 274572 contains 8 rings... buy two and it can be cheaper than buying the 12 box



mutlitech 2

ACD# 217-1427 GM#12570621

Share this post


Link to post
Share on other sites

MOOG suspension bushings for GEN 1/1.5 sway bars (blue rubber? ones)



(34mm bar) inner: MOOG Part # K6457 {Sway Bar Bushing Kit} Front Suspension; To Frame; w/1-5/16" Bar

(all bars) outer: MOOG Part # K6641 {Sway Bar Bushing Kit} Front Suspension; To Control Arm

Edited by Crazy K

Share this post


Link to post
Share on other sites

I just tried to order a new vac spider #10114903 for my TGP from gmpartsdirect.com and the order was cancelled because the part is no longer available.

Figured that might be good info to get out there. These vac spiders are becoming harder to get.

Share this post


Link to post
Share on other sites

Something that is very recommended when doing deep engine work is to use revised problem solving intake gaskets so you don't have the risk of having to do the job twice, or worse. here they are:



3800 gasket sets:
FEL-PRO Part # MS98014T PermaDryPlus®; Intake Manifold Gasket Set
FEL-PRO Part # VS50465R PermaDry® Valve Cover Gasket
*head gaskets and upper intake gaskets may vary by application in normally aspirated verses forced induction*



3x00
Metal Intake Manifold Gaskets FEL-PRO Part # MS98004T PermaDryPlus®; with upper gaskets and seals. for SMALL port intake, L82 (Vin M)
Metal Intake Manifold Gaskets FEL-PRO Part # MS98003T PermaDryPlus®; with upper gaskets and seals. for LARGE port intake, LG8 3100 (Vin J), LA1 3400 (Vin E)

Share this post


Link to post
Share on other sites

Coolant Pipe. Original Thread Here: http://www.w-body.com/showthread.php/77468-repairing-ruptured-coolant-pipe



The original part is GM # 10145142. There's an aftermarket Dorman replacement, #626-100. They run about $30 shipped on eBay.

http://www.ebay.com/itm/DORMAN-626-100-Heater-Hose-/390597626865?pt=Motors_Car_Truck_Parts_Accessories&hash=item5af16ecbf1&vxp=mtr



A rubber hose might last longer, but the OEM style part should also last at least a decade.

Edited by runt

Share this post


Link to post
Share on other sites
Someone suggested we have a Thread dedicated to parts numbers, And that is an excellent Idea. I'm going to keep this open and you can post whatever you feel is helpful to the community. I will be deleting the replys after I paste them into this Post to keep it uncluttered.



Unless noted these are Manufacturer Part numbers and will be the same regardless of who you buy from





Brakes:



Power Master III Parts:

88927271 / 18M874 - accumulator

88927270 - pressure switch

SIA Electronics - Call for pricing and parts (800) 737-0915



Goodridge SS brake lines:

'88-'90 W - GS12264

'94-'97 W - GS12237



Suspension:

GMPP rear trailing arms - 12498649 <- On indefinite national backorder

Police Package Impala trailing arms- 15856683 - QTY2

Hub to knuckle bolts(1 and 1.5 gen front only) - 10104548



KYB GR2/Excel G Front Sturts - 366004

KYB GR2/Excel G Rear Struts - 236003



Energy Suspension greasable poly sway bar bushings (when using 34mm front sway bar) - 9.5160G and 9.5167G



Rear sway bar bracket - 10259660





Engine:

Oil Filters:

2.8/3.1/3x00/3800 - PF47

3.4 - PF52

Note: You can use the PF52 on just about anything that calls for a PF47.



Knock Sensor (genII 60*)- 10456208

Crank Position Sensor (CPS) (GenII 60*) - 10456555



oil/distributor drive O-Ring - 10477565



Oil plug bolt thread size - M12-1.75

Oil drain plug - 10017615

aftermarket Magnetic plug - Motormite "Oil-tite!" 65372

Dorman Quick Disconnect 800-401 - Cooling System Connector that screws into the LIM of 3.1mpfi, earlier 3100sfi, earlier 3400sfi, and 3.4DOHC cars.



3.4 DOHC Timing Belt Parts:

24502982 - Belt

24503561 - Tensioner Pulley

10162013 - Tensioner Pulley Bolt

24503859 - Idler Pulley, 2 needed

24503860 - Tensioner Actuator

24503861 - Tensioner Actuator mounting plate.



89017825 - Improved aluminum Series II 3800 intake gaskets



2.8/3.1 Throttle Body gasket - Fel-pro 60728



91-97 LQ1 Solid rubber engine mount - DEA/Pioneer P/N - A2555 (Available from Autozone)

88-93 2.8/3.1 Solid rubber engine mount - DEA/Pioneer P/N - A2660 (Available from Autozone)

94-96 3100 Solid rubber engine mount - DEA/Pioneer P/N - A2796 (Available from Autozone)

97-04 W-Body Solid rubber engine mount(EXCEPT 3.5L Intrigue) - DEA/Pioneer P/N - A2796 (Available from Autozone)



2.8/3.1 Oil Pressure Sending Unit w/ Gauge (Seems to be for any 60 degree W from 89-90): GM part number 10201491.





Transmission:



4T60-E VSS - 10456034



4T60-E Parking Brake Actuator - 24213560



Getrag 284

Spec Stage II Clutch - SC272

Output Shaft Seals Timken P/N - 2003N

284 select cable - 10192248

284 Slave Cylinder - 12550806



282/284 Clutch pedal bushing - 14091384



Interior:



GM W-body Door Key "C": 12390306

GM W-body Ingition Key "D": 26002688

GM W-body Ignition key "E": 26024974





Body/Misc:



97-00 - Regal GS and Grand Prix GTP fuel pump resistor - 88951182



1st gen Hood release cable - 10167401



94-96 GP Fender flare Clips - 10229345



Power steering rack pressure switch - 10238816



Subframe Bushings

14088025 - QTY2

14088026 - QTY2

14088027 - QTY2

14088028 - QTY2



Subframe Bolts

10220561 - QTY4



Subframe Retainers

10139080 - QTY2

10203413 - QTY2



Fuel Tank Lines for 88-91 W bodys

10062887 PIPE ASM FUEL RTN

10062888 PIPE ASM FUEL FEED



AC Accumulator:

4 Season's PN# 33206 - VERY useful for 284 cars and Turbo Grand Prix











I AM LOOKING FOR GM PART #24503861 DO YOU KNOW WHERE I CAN GET THIS. I KNOW THAT IT IS DISCONTINUED.

Share this post


Link to post
Share on other sites

for the most well done(crustiest) of w-bodies:



having to replace all of the fittings due to running new brake lines from front to rear, it appears that all of the line nuts in the braking system of the 95 monte carlo uses a M10-1.0 thread with the exception of 2 of the master cylinder line nuts, those appear to be M11-1.5. I imagine this applies to at least all w-bodies with ABS VI, but the non-ABS cars are probably similar/identical. can't speak for PM3.

Share this post


Link to post
Share on other sites

- Dorman trailing arm replacements (square tube, not U-channel like the stockers) p/n 905-501 (pair)

- Dorman trailing arm brackets to frame (these usually rot out) p/n 523-023 (97-up)

- Dorman front sway bar (33mm diameter) p/n 927-100 (97-up)

- Dorman rear sway bar (16mm diameter) p/n 927-110 (97-up)

- Moog "problem solver" front end links (urethane bushings, barrel nut, extra thick center section) p/n K700527 (97-up)
