1996 Cutlass Supreme- Rear Stabilizer Link Hangers


  • Please log in to reply
25 replies to this topic

#1 bluecalais79

bluecalais79

    Member

  • Members
  • PipPip
  • 115 posts

Posted 29 March 2018 - 01:27 PM

Does anyone know a part source for the 2 hangers that bolt onto the frame for the 2 rear sway bar stabilizer links? I am in the process of replacing all these as they are badly rusted. The hangers are in such bad shape I am worried they are going to fall apart in pieces (or even rust dust!) when I unbolt the links from them. I can't seem to find these anywhere. I've got the links, bushings, end links, end bushings, etc. ready to go, so the hangers are the last pieces to the puzzle needed.

Attached Files



#2 94 olds vert

94 olds vert

    Executive Member

  • Contributing Member
  • 10,813 posts
  • LocationRay, MI

Posted 29 March 2018 - 01:53 PM

This part here?



new sig 3.jpg

1994 Cutlass Supreme Convertible [2Q 2012 COTQ]

2000 Grand Prix GTP 2015 GMC Sierra Z71 SOLD

2006 Chevrolet Silverado


#3 bluecalais79

bluecalais79

    Member

  • Members
  • PipPip
  • 115 posts

Posted 29 March 2018 - 02:37 PM

Will have to look at the photo this evening, the system here x's it out. Thanks, I'll take a look. Any chance you have 2 of them?



#4 94 olds vert

94 olds vert

    Executive Member

  • Contributing Member
  • 10,813 posts
  • LocationRay, MI

Posted 29 March 2018 - 03:02 PM

You are referring to that white Cutlass in your first post, right?

new sig 3.jpg

1994 Cutlass Supreme Convertible [2Q 2012 COTQ]

2000 Grand Prix GTP 2015 GMC Sierra Z71 SOLD

2006 Chevrolet Silverado


#5 Imp558

Imp558

    Proud TransCelestialsexual

  • Moderators
  • 5,475 posts
  • LocationErie PA.

Posted 29 March 2018 - 03:18 PM

Rockauto has them, armed with part numbers you might find a better deal than $9.00 but I doubt it.



ACDELCO 45G0406



MOOG K80233



  • rich_e777, Galaxie500XL and 94 olds vert like this


"If everything seems under control, you're not going fast enough" - Mario Andretti

1996 Buick Regal L67/4T65E-HD swapped - 1995 Buick Regal GS - 1980 Dodge Sno-Commander - 1968 Empi Imp on '67 Pan - 2001 Chevrolet Express 3500

Her Stuff: 1996 SSEi - 2001 Monte Carlo SS


#6 bluecalais79

bluecalais79

    Member

  • Members
  • PipPip
  • 115 posts

Posted 29 March 2018 - 03:29 PM

Thanks, pictured above is the sway bar link, 2 of them are used to support/hold the sway bar. The top of the link above bolts onto a hanger, that's the part I'm looking for, The hanger bolts to the frame. Oddly enough my frame is mint in great shape but the hanger it crumpled, rusted away very badly.



Yep that's my 1996 Cutlass up there. You can picture it with a correct white lip spoiler & tails, they will all be going on in a few weeks. :)


  • Galaxie500XL likes this

#7 Imp558

Imp558

    Proud TransCelestialsexual

  • Moderators
  • 5,475 posts
  • LocationErie PA.

Posted 29 March 2018 - 03:46 PM

How are the trailing arm mounts that Nate posted a picture of? Those have been the death of many a W-Body but we have a fix for that now too.


  • 94 olds vert likes this


"If everything seems under control, you're not going fast enough" - Mario Andretti

1996 Buick Regal L67/4T65E-HD swapped - 1995 Buick Regal GS - 1980 Dodge Sno-Commander - 1968 Empi Imp on '67 Pan - 2001 Chevrolet Express 3500

Her Stuff: 1996 SSEi - 2001 Monte Carlo SS


#8 bluecalais79

bluecalais79

    Member

  • Members
  • PipPip
  • 115 posts

Posted 29 March 2018 - 05:06 PM

I'll have to wait until I get home to see those photos, I'm not able to see them here at work. I will say though, that both my trailing arms have been replaced NOS GM.



This car had only 58,xxx miles on it when I bought it but it was a neglected Sir-Sits-A lot. It was old lady owned and also old lady not used, and it did it's sitting outside, an Indiana car. . So, all the weaker metal parts on this car are badly rusted. I'm going through the motions of replacing what I can.The frame and body panels though, are M-I-N-T and the motor is as strong as an ox (3.1). The miles were documented when I bought the car. Had this car been an inside sitter, man that would have been something. But it wasn't. I think the shipper probably broke one of the trailing arms by strapping it during shipping. No matter as I could have squeezed and busted the other one myself it was so bad. All lines and hoses and I mean all were so badly corroded they've all been replaced. Full brake job on all corners too.



But this car was worth it due to the low mileage and the fact I got it so cheaply. No coolant seepage into the oil yet either, but I'm sure that day is coming. It's been a great car since all this work has been done,  now I just have to drive it to get the value out of what I put into it for say, the next 10 years. I heard you can get 300,000+++ miles out of these motors if you treat 'em right, I think that would be about right.



And besides, how many people out there (outside this inner circle) can still say they are driving a Cutlass to work everyday? Used to be millions, now it's just me.


  • Imp558 and oldmangrimes like this

#9 Imp558

Imp558

    Proud TransCelestialsexual

  • Moderators
  • 5,475 posts
  • LocationErie PA.

Posted 29 March 2018 - 05:30 PM

There's an opening where the trailing arm mounts drop out of the "frame" where moisture collects. A weld shop can cut the rot out and plate it with 1/8" steel and weld a second gen mount on. My Regal and Miller's Regal both had the procedure.


  • vipmiller803 likes this


"If everything seems under control, you're not going fast enough" - Mario Andretti

1996 Buick Regal L67/4T65E-HD swapped - 1995 Buick Regal GS - 1980 Dodge Sno-Commander - 1968 Empi Imp on '67 Pan - 2001 Chevrolet Express 3500

Her Stuff: 1996 SSEi - 2001 Monte Carlo SS


#10 bluecalais79

bluecalais79

    Member

  • Members
  • PipPip
  • 115 posts

Posted 29 March 2018 - 05:43 PM

That sounds like a good gig, I was relieved to hear this wasn't needed by the shop that installed the new Trailing Arms (he's a fellow OCA member and knows these cars inside out)



#11 vipmiller803

vipmiller803

    Advanced Member

  • Contributing Member
  • 449 posts
  • LocationDetroit, MI

Posted 29 March 2018 - 06:25 PM

There's an opening where the trailing arm mounts drop out of the "frame" where moisture collects. A weld shop can cut the rot out and plate it with 1/8" steel and weld a second gen mount on. My Regal and Miller's Regal both had the procedure.

Actually my regal ended up getting the original mount braced front and back. No second gen mount for me - yet. The one I ordered still sits on the shelf...



But yea those are the sway bar mounts. I have seen the bar rust onto the bushing that goes in that mount enough to take maybe 3/16" of the bar diameter so look for that when you're changing them.


Edited by vipmiller803, 29 March 2018 - 06:29 PM.

1995 Buick Regal Custom 2DR - 3.8L - DD - 4th Engine, 3rd Transmission, and counting...

2001 Dodge Ram 2500 4x4 - 5.9L Gas

1993 Jeep GC LTD - 4.0L - Snow Days Ride


#12 Imp558

Imp558

    Proud TransCelestialsexual

  • Moderators
  • 5,475 posts
  • LocationErie PA.

Posted 29 March 2018 - 06:32 PM

Actually my regal ended up getting the original mount braced front and back. No second gen mount for me - yet. The one I ordered still sits on the shelf...



No kidding, the Regal's still the only one. That was conceived of by L67SS a long time ago and now the only example of the repair is going to get scrapped due to accident damage. Bummer



"If everything seems under control, you're not going fast enough" - Mario Andretti

1996 Buick Regal L67/4T65E-HD swapped - 1995 Buick Regal GS - 1980 Dodge Sno-Commander - 1968 Empi Imp on '67 Pan - 2001 Chevrolet Express 3500

Her Stuff: 1996 SSEi - 2001 Monte Carlo SS


#13 Galaxie500XL

Galaxie500XL

    Senior Member

  • Contributing Member
  • 2,934 posts
  • LocationKnoxville, Tennessee

Posted 29 March 2018 - 10:32 PM

I'll have to wait until I get home to see those photos, I'm not able to see them here at work. I will say though, that both my trailing arms have been replaced NOS GM.



This car had only 58,xxx miles on it when I bought it but it was a neglected Sir-Sits-A lot. It was old lady owned and also old lady not used, and it did it's sitting outside, an Indiana car. . So, all the weaker metal parts on this car are badly rusted. I'm going through the motions of replacing what I can.The frame and body panels though, are M-I-N-T and the motor is as strong as an ox (3.1). The miles were documented when I bought the car. Had this car been an inside sitter, man that would have been something. But it wasn't. I think the shipper probably broke one of the trailing arms by strapping it during shipping. No matter as I could have squeezed and busted the other one myself it was so bad. All lines and hoses and I mean all were so badly corroded they've all been replaced. Full brake job on all corners too.



But this car was worth it due to the low mileage and the fact I got it so cheaply. No coolant seepage into the oil yet either, but I'm sure that day is coming. It's been a great car since all this work has been done,  now I just have to drive it to get the value out of what I put into it for say, the next 10 years. I heard you can get 300,000+++ miles out of these motors if you treat 'em right, I think that would be about right.



And besides, how many people out there (outside this inner circle) can still say they are driving a Cutlass to work everyday? Used to be millions, now it's just me.

My old LQ1 Cutlass had just over 250,000 miles on it, and was being driven more or less daily when I sold it to another W-body member..other than a small blue puff of smoke on startup (likely valve guides), it still ran and sounded great.  It's still being driven.


galaxie500xl

1993 LT1 Corvette Coupe

1988 Camaro IROC-Z 5.7 TPI 5-speed

2015 Chevrolet Equinox LTZ

GONE to a new home... 1995 Cutlass DOHC Convertible, 3rd Quarter 2012 W-Body.com COTQ


#14 rich_e777

rich_e777

    Interweb SortAScrub

  • Contributing Member
  • 2,196 posts
  • LocationNashville,TN

Posted 29 March 2018 - 10:59 PM

Thanks, pictured above is the sway bar link, 2 of them are used to support/hold the sway bar. The top of the link above bolts onto a hanger, that's the part I'm looking for, The hanger bolts to the frame. Oddly enough my frame is mint in great shape but the hanger it crumpled, rusted away very badly.



Yep that's my 1996 Cutlass up there. You can picture it with a correct white lip spoiler & tails, they will all be going on in a few weeks. :)

I believe I haz what you are looking for, and IIRC they are the same bracket regardless of the diameter of the sway bar. The junkyard is the only place to find them though, Ive got a pair from a 1st gen Z34 for the rear bar I was planning to put on my 94 CS. I might go JY this Sat. and will grab any that are there.


  • bluecalais79 likes this

1994 Olds Cutlass Supreme Coupe-2004

1999 Pontiac Grand Prix GTP Coupe 2015 RIP

1995 Olds Cutlass Supreme Convertible-2016

2006 Dodge Ram 1500 Crew-2017

???-2018 (assuming the trend continues)


#15 rich_e777

rich_e777

    Interweb SortAScrub

  • Contributing Member
  • 2,196 posts
  • LocationNashville,TN

Posted 29 March 2018 - 11:21 PM

My old LQ1 Cutlass had just over 250,000 miles on it, and was being driven more or less daily when I sold it to another W-body member..other than a small blue puff of smoke on startup (likely valve guides), it still ran and sounded great.  It's still being driven.

254k ATM



I'll have to wait until I get home to see those photos, I'm not able to see them here at work. I will say though, that both my trailing arms have been replaced NOS GM.



This car had only 58,xxx miles on it when I bought it but it was a neglected Sir-Sits-A lot. It was old lady owned and also old lady not used, and it did it's sitting outside, an Indiana car. . So, all the weaker metal parts on this car are badly rusted. I'm going through the motions of replacing what I can.The frame and body panels though, are M-I-N-T and the motor is as strong as an ox (3.1). The miles were documented when I bought the car. Had this car been an inside sitter, man that would have been something. But it wasn't. I think the shipper probably broke one of the trailing arms by strapping it during shipping. No matter as I could have squeezed and busted the other one myself it was so bad. All lines and hoses and I mean all were so badly corroded they've all been replaced. Full brake job on all corners too.



But this car was worth it due to the low mileage and the fact I got it so cheaply. No coolant seepage into the oil yet either, but I'm sure that day is coming. It's been a great car since all this work has been done,  now I just have to drive it to get the value out of what I put into it for say, the next 10 years. I heard you can get 300,000+++ miles out of these motors if you treat 'em right, I think that would be about right.



And besides, how many people out there (outside this inner circle) can still say they are driving a Cutlass to work everyday? Used to be millions, now it's just me.

I DD`d my 94 CS for nearly 13 years before I retired her to the driveway for a resto-modding project. Shes only at 133k and aside from the PASSKEY?LOCK? whatever bullshit anti-theft resistor that prevents me from starting it randomly, everything works. Its cleverly disguised as a POS but I know every inch of it and have a garage full of parts just waiting for things to happen.


1994 Olds Cutlass Supreme Coupe-2004

1999 Pontiac Grand Prix GTP Coupe 2015 RIP

1995 Olds Cutlass Supreme Convertible-2016

2006 Dodge Ram 1500 Crew-2017

???-2018 (assuming the trend continues)


#16 rich_e777

rich_e777

    Interweb SortAScrub

  • Contributing Member
  • 2,196 posts
  • LocationNashville,TN

Posted 29 March 2018 - 11:24 PM

This part here?


Other end, what the inside sway bar links bolt to that connect the link to the frame.


  • 94 olds vert likes this

1994 Olds Cutlass Supreme Coupe-2004

1999 Pontiac Grand Prix GTP Coupe 2015 RIP

1995 Olds Cutlass Supreme Convertible-2016

2006 Dodge Ram 1500 Crew-2017

???-2018 (assuming the trend continues)


#17 94 olds vert

94 olds vert

    Executive Member

  • Contributing Member
  • 10,813 posts
  • LocationRay, MI

Posted 29 March 2018 - 11:27 PM

I had a hard time picturing that part for some reason.

new sig 3.jpg

1994 Cutlass Supreme Convertible [2Q 2012 COTQ]

2000 Grand Prix GTP 2015 GMC Sierra Z71 SOLD

2006 Chevrolet Silverado


#18 bluecalais79

bluecalais79

    Member

  • Members
  • PipPip
  • 115 posts

Posted 29 March 2018 - 11:50 PM

Other end, what the inside sway bar links bolt to that connect the link to the frame.‚Äč....per that note above, yup, these are what's toast, Rich e77 if you want to sell 'em. I'll buy 'em



#19 rich_e777

rich_e777

    Interweb SortAScrub

  • Contributing Member
  • 2,196 posts
  • LocationNashville,TN

Posted 30 March 2018 - 12:16 AM

Let me see what I can find Sat which would just be whatever shipping is, the pair I have I really need for the 94 FE3+ project.


1994 Olds Cutlass Supreme Coupe-2004

1999 Pontiac Grand Prix GTP Coupe 2015 RIP

1995 Olds Cutlass Supreme Convertible-2016

2006 Dodge Ram 1500 Crew-2017

???-2018 (assuming the trend continues)


#20 bluecalais79

bluecalais79

    Member

  • Members
  • PipPip
  • 115 posts

Posted 30 March 2018 - 10:46 AM

Thanks, that's a plan.
